Categories | Indoor Fiber Optic Cable |
---|---|
Brand Name: | OEM |
Model Number: | ORCA010 |
Certification: | ISO9001 |
Place of Origin: | CHINA |
MOQ: | Support sample order |
Price: | Negotiation |
Payment Terms: | T/T, Western Union, L/C |
Delivery Time: | 3-7 work days |
Packaging Details: | 1KM / 2KM or other contracted length per roll |
Fiber Type: | G652/G657/G655/A1a/A1b |
Cable Material: | LSZH/PVS/ZRPO/OFNR/OFNP |
Fiber Count: | 16F/24F/36F/48F/64F/72F/96F/144F |
Operation Temperature: | -20℃-+60℃ |
Jacket / Buffer Color: | meets the requirement of relevant standards |
Cable Dimension: | 12.5mm/15mm/17mm/18.5mm/22mm/22.5mm/25.5mm/33.5mm |
Company Info. |
Optic River Communication Ltd |
View Contact Details |
Product List |
Fiber Count | Subunit Count | Fiber Count in Each Unit | Cable Dimension(mm) | Cable Weight(kg/km) | Tensile(N) | Crush(N/100mm) | Min. Bend Radius(mm) | Range of Temperature(℃) | |||
Long Term | Short Term | Long Term | Short Term | Dynamic | Static | ||||||
16 | 4 | 4 | 12.5 | 125 | 400 | 1320 | 300 | 1000 | 20D | 10D | -20-+60 |
24 | 6 | 4 | 15.0 | 183 | 400 | 1320 | 300 | 1000 | |||
36 | 6 | 6 | 17.0 | 238 | 400 | 1320 | 300 | 1000 | |||
48 | 6 | 8 | 18.5 | 292 | 400 | 1320 | 300 | 1000 | |||
64 | 8 | 8 | 22.0 | 410 | 400 | 1320 | 300 | 1000 | |||
72 | 6 | 12 | 22.5 | 390 | 400 | 1320 | 300 | 1000 | |||
96 | 8 | 12 | 25.5 | 546 | 600 | 1500 | 300 | 1000 | |||
144 | 12 | 12 | 33.5 | 1004 | 1000 | 2000 | 300 | 1000 | |||
Note: 1. All the values provided in the table, which are for your reference, are subject to chanfe without notice; 2. The cable dimension and weight are in accordance with tight-buffered fiber with 0.9mm outer diameter; 3. D is outer diameter of the round cable; 4. The minimum bend radius (static) is 5D when G.657 fiber is used. |
Product Advantages
![]() |
