Categories | Indoor Fiber Optic Cable |
---|---|
Brand Name: | OEM |
Model Number: | ORCA015 |
Certification: | ISO9001 |
Place of Origin: | CHINA |
MOQ: | Support sample order |
Price: | Negotiation |
Payment Terms: | T/T, Western Union, L/C |
Delivery Time: | 3-7 work days |
Packaging Details: | 1KM / 2KM or other contracted length per roll |
Fiber Type: | G652/G657/G655/A1a/A1b |
Cable Material: | LSZH/PVS/ZRPO/OFNR/OFNP |
Fiber Count: | 2F/4F/6F/8F/12 Fiber |
Operation Temperature: | -20℃-+60℃ |
Jacket / Buffer Color: | meets the requirement of relevant standards |
Cable Dimension: | 3.0mm*3.5mm/3.0mm*4.3mm/3.0mm*4.9mm/3.0mm*6.0mm |
Company Info. |
Optic River Communication Ltd |
View Contact Details |
Product List |
Fiber Count | Cable Dimension(mm) | Cable Weight(kg/km) | Tensile(N) | Crush(N/100mm) | Min Bend. Radius(mm) | Range of Temperature(℃) | |||
Long Term | Short Term | Long Term | Short Term | Dynamic | Static | ||||
2 | 3.0X3.5 | 9.6 | 80 | 200 | 200 | 500 | 50 | 30 | -20-+60 |
4 | 3.0X3.5 | 9.7 | 80 | 200 | 200 | 500 | -20-+60 | ||
6 | 3.0X4.3 | 12.2 | 80 | 200 | 200 | 500 | -20-+60 | ||
8 | 3.0X4.9 | 14.1 | 80 | 200 | 200 | 500 | -20-+60 | ||
12 | 3.0X6.0 | 17.5 | 80 | 200 | 200 | 500 | -20-+60 | ||
Note: 1. All the values in the table, which are for reference only, are subject to change without notice; 2. The cable dimension and weight are in accordance with tight-buffered fiber with 0.9mm outer diameter; 3. The cable dimension in the table, which are according to single ribbon, are subject to change with the ribbon count; 4. The minimum bend radius(static) is 5D when G.657 fiber is used. |
