200L Integrated Pressure Copper Coil Pre Heated Solar Water heater Color Steel Type For Home

200L Integrated Pressure Copper Coil Pre Heated Solar Water heater Color Steel Type For Home

1. ISO9001, CE, approved
2. OEM offered
3. Good sales in EU /NA

Work principle

The water in water tank is for heat preservation and circulation. The vacuum tube collector absorbs sunshine to heat the water in water tank, when using the hot water, the cold water flows through the inlet, the copper coil absorbs heat then transfer to the cold water, so that temperature rise up ceaselessly, due to the original feature of the copper coil, the water temperature of the outlet is close to the water temperature of water tank(difference within 3 degree centigrade). Therefore, cold water flow via copper coil and absorbs much heat, when water flow past outlet, the temperature is usually hot enough to use.

-

Application area

Good solution for areas where people have demand for good water quality

For cold areas people have a large demand for hot water

Places where there is daily needs of hot water

-

Structure

It has a storage tank with copper coil installed inside, assistant tank, exhaust pipe on the top of the tank and vacuum tubes with heat pipes.

-

Specification

Water tank: SUS304-2B stainless steel plate(0.4mm) for inner water tank; galvanized /color steel plate(0.4mm) for tank shell; Polyurethane integral foaming(50-60mm) for insulation; 15m copper coil for normal

Bracket: Anti-corrosion galvanized /color steel plate ( 1.2-1.5mm), aluminum alloy profiled bar (1.5-2.0mm), stainless steel(1.0mm); dual-purpose bracket for both flat and sloping roof

Vacuum tube: D58mm*1800mm, D47mmx1500mm

Accessories: Assistant tank(5L),- Electric heater, Controller

Features

1. It can withstand pressure of tap water when it works, and copper coil in tank bear pressure.

2. Use in any time: it adopts advanced design idea and integrates with high efficiency preheated patent technique.

3. High quality SUS304-2B stainless steel for inner water tank, processed by argon arc welding technique, under

strict quality control system, tank will never rust and leak.

4. Relevant accessories are optional instead of compulsory, client can choose some or none according to actual need.

5. 6. It can produce hot water with constant temperature.

7. It’s indirect solar system, so water quality is superior, much cleaner than direct solar system.

8. Time of uploading water is cut, 24 hours water supply on condition that pipeline is working.

9. Life duration: 15 years, warranty: 5 years

10. OEM/ODM offered

PDF Catalogue of Pre-heated Solar Water Heater with Heat Exchanger.

PT-P Pre-heated Solar Water Heater with Heat Excha...
