37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque

Name: 37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
Brand: TYHE
Price: 1 USD

37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque

Categories	DC Spur Gear Motor
Brand Name:	TYHE
Model Number:	TJP37RK
Certification:	CE/ROHS/ISO9001
Place of Origin:	China
MOQ:	500pcs
Price:	Negotiation
Payment Terms:	T/T, Western Union
Supply Ability:	100000pcs per month
Delivery Time:	15 working days after payment
Packaging Details:	Foam wrapped, carton packed
Size:	37mm
Voltage:	3-24V
Speed:	20rpm 25rpm 30rpm 50rpm or Customized
Torque:	1.5N.m
Gear material:	Powder metallurgy, steel
Commutation:	Brush
Type:	Gear Motor, Micro Motor
Usage:	Popcorn machine
Keywords:	37GB3530R 37mm Powder Gears 6v 7v 12v 18kg Torque Brushed Dc Gear Motor

Contact Now

Add to Cart

Company Info.

Wenzhou Tyhe Motor Co., Ltd.

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque

Products Description

37GB3530R 37mm Powder Gears 6v 7v 12v 18kg Torque Brushed Dc Gear Motor

2D drawing


Specifications

DC Motor Technical Data
Model	Rated Voltage(V)	No-Load Parameters		Rated Parameters					Stall Parameters
		Speed	Current	Speed	Current	Torque	Output	eff	Torque	Current
		rpm	mA	rpm	A	mN.m	W	%	mN.m	A
ZY3530	12	5500	60	4400	0.23	3.81	1.76	62.69	11.43	1.72
ZY3530	12	6500	65	5200	0.31	4.18	2.28	61.18	12.54	2.00
ZY3530	12	7300	67	5840	0.36	4.35	2.66	61.78	13.05	3.10
ZY3530	12	9000	90	7200	0.43	4.31	3.25	63.47	12.93	3.50
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters			12V-5500RPM Input				12V-6500RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
22.5	81	6.5	676.9	1.42	20.06	60.18	800.0	1.84	22.01	66.02
22.5	81	7.6	578.9	1.42	23.45	70.36	684.2	1.84	25.73	77.20
22.5	73	9.3	473.1	1.28	25.87	77.60	559.1	1.66	28.38	85.13
22.5	73	11.8	372.9	1.28	32.82	98.46	440.7	1.66	36.01	108.02
22.5	73	15.2	289.5	1.28	42.28	126.83	342.1	1.66	46.38	139.14
22.5	73	20.4	215.7	1.28	56.74	170.22	254.9	1.66	62.25	186.75
24.5	65.6	27.5	160.0	1.15	68.73	206.20	189.1	1.49	75.41	226.22
24.5	65.6	35.6	123.6	1.15	88.98	266.93	146.1	1.49	97.62	292.85
24.5	65.6	41.6	105.8	1.15	103.97	311.92	125.0	1.49	114.07	342.21
24.5	65.6	57.7	76.3	1.15	144.21	432.64	90.1	1.49	158.22	474.65
26.5	59	73.4	59.9	1.04	165.00	494.99	70.8	1.34	181.02	543.06
26.5	59	83	53.0	1.04	186.58	559.73	62.7	1.34	204.69	614.08
26.5	59	97	45.4	1.04	218.05	654.14	53.6	1.34	239.22	717.66
26.5	59	111	39.6	1.04	249.52	748.55	46.8	1.34	273.75	821.24
26.5	59	119	37.0	1.04	267.50	802.50	43.7	1.34	293.48	880.43
26.5	59	130	33.8	1.04	292.23	876.68	40.0	1.34	320.61	961.82
29.5	53	194	22.7	0.93	391.74	1175.23	26.8	1.21	429.79	1289.36
29.5	53	226	19.5	0.93	456.36	1369.09	23.0	1.21	500.68	1502.04
29.5	53	259	17.0	0.93	523.00	1569.00	20.1	1.21	573.79	1721.37
29.5	53	277	15.9	0.93	559.35	1678.04	18.8	1.21	613.67	1841.00
29.5	53	303	14.5	0.93	611.85	1835.54	17.2	1.21	671.27	2013.80
29.5	53	316	13.9	0.93	638.10	1914.30	16.5	1.21	700.07	2100.20
29.5	53	346	12.7	0.93	698.68	2096.03	15.0	1.21	766.53	2299.59
29.5	53	382	11.5	0.93	771.37	2314.12	13.6	1.21	846.28	2500.00
32.5	47.8	452	9.7	0.84	823.17	2469.52	11.5	1.09	903.11	2500.00
32.5	47.8	528	8.3	0.84	961.58	2500.00	9.8	1.09	1054.97	2500.00
32.5	47.8	604	7.3	0.84	1099.99	2500.00	8.6	1.09	1206.82	2500.00
32.5	47.8	665	6.6	0.84	1211.08	2500.00	7.8	1.09	1328.70	2500.00
32.5	47.8	733	6.0	0.84	1334.92	2500.00	7.1	1.09	1464.56	2500.00
32.5	47.8	808	5.4	0.84	1471.51	2500.00	6.4	1.09	1614.42	2500.00
32.5	47.8	890	4.9	0.84	1620.85	2500.00	5.8	1.09	1778.26	2500.00
32.5	43	1232	3.6	0.75	2018.39	2500.00	4.2	0.98	2214.40	2500.00
32.5	43	1408	3.1	0.75	2306.73	2500.00	3.7	0.98	2500.00	2500.00
32.5	43	1552	2.8	0.75	2500.00	2500.00	3.4	0.98	2500.00	2500.00
32.5	43	1711	2.6	0.75	2500.00	2500.00	3.0	0.98	2500.00	2500.00
32.5	43	2077	2.1	0.75	2500.00	2500.00	2.5	0.98	2500.00	2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters			12V-7300RPM Input				12V-9000RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
22.5	81	6.5	898.5	2.15	22.90	68.71	1107.7	2.63	22.69	68.08
22.5	81	7.6	768.4	2.15	26.78	80.34	947.4	2.63	26.53	79.60
22.5	73	9.3	628.0	1.94	29.53	88.60	774.2	2.37	29.26	87.78
22.5	73	11.8	494.9	1.94	37.47	112.41	610.2	2.37	37.13	111.38
22.5	73	15.2	384.2	1.94	48.27	144.80	473.7	2.37	47.82	143.47
22.5	73	20.4	286.3	1.94	64.78	194.34	352.9	2.37	64.18	192.55
24.5	65.6	27.5	212.4	1.75	78.47	235.42	261.8	2.13	77.75	233.26
24.5	65.6	35.6	164.0	1.75	101.59	304.76	202.2	2.13	100.65	301.96
24.5	65.6	41.6	140.4	1.75	118.71	356.13	173.1	2.13	117.62	352.85
24.5	65.6	57.7	101.2	1.75	164.65	493.96	124.8	2.13	163.14	489.42
26.5	59	73.4	79.6	1.57	188.38	565.14	98.1	1.92	186.65	559.95
26.5	59	83	70.4	1.57	213.02	639.06	86.7	1.92	211.06	633.18
26.5	59	97	60.2	1.57	248.95	746.85	74.2	1.92	246.66	739.98
26.5	59	111	52.6	1.57	284.88	854.64	64.9	1.92	282.26	846.79
26.5	59	119	49.1	1.57	305.41	916.24	60.5	1.92	302.61	907.82
26.5	59	130	44.9	1.57	333.65	1000.94	55.4	1.92	330.58	991.73
29.5	53	194	30.1	1.41	447.27	1341.80	37.1	1.72	443.15	1329.46
29.5	53	226	25.8	1.41	521.04	1563.13	31.9	1.72	516.25	1548.76
29.5	53	259	22.5	1.41	597.12	1791.37	27.8	1.72	591.63	1774.90
29.5	53	277	21.1	1.41	638.62	1915.87	26.0	1.72	632.75	1898.25
29.5	53	303	19.3	1.41	698.57	2095.70	23.8	1.72	692.14	2076.43
29.5	53	316	18.5	1.41	728.54	2185.61	22.8	1.72	721.84	2165.52
29.5	53	346	16.9	1.41	797.70	2393.11	20.8	1.72	790.37	2371.10
29.5	53	382	15.3	1.41	880.70	2500.00	18.8	1.72	872.60	2500.00
32.5	47.8	452	12.9	1.27	939.84	2500.00	15.9	1.55	931.20	2500.00
32.5	47.8	528	11.1	1.27	1097.87	2500.00	13.6	1.55	1087.78	2500.00
32.5	47.8	604	9.7	1.27	1255.90	2500.00	11.9	1.55	1244.35	2500.00
32.5	47.8	665	8.8	1.27	1382.73	2500.00	10.8	1.55	1370.02	2500.00
32.5	47.8	733	8.0	1.27	1524.13	2500.00	9.8	1.55	1510.11	2500.00
32.5	47.8	808	7.2	1.27	1680.07	2500.00	8.9	1.55	1664.63	2500.00
32.5	47.8	890	6.6	1.27	1850.58	2500.00	8.1	1.55	1833.56	2500.00
32.5	43	1232	4.7	1.14	2304.46	2500.00	5.8	1.40	2283.27	2500.00
32.5	43	1408	4.1	1.14	2500.00	2500.00	5.1	1.40	2500.00	2500.00
32.5	43	1552	3.8	1.14	2500.00	2500.00	4.6	1.40	2500.00	2500.00
32.5	43	1711	3.4	1.14	2500.00	2500.00	4.2	1.40	2500.00	2500.00
32.5	43	2077	2.8	1.14	2500.00	2500.00	3.5	1.40	2500.00	2500.00

Please let us know your requirements and we will provide you with transmission solutions.
