| Categories | Aircraft Tow Tractor |
|---|---|
| Brand Name: | TECHKING |
| Model Number: | TK-QY180 |
| Certification: | CCC |
| Place of Origin: | CHINA |
| MOQ: | 1 |
| Price: | By negociation |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 10 Units/Month |
| Delivery Time: | 120 days |
| Packaging Details: | Nude Pack, Loaded in Flat Rack Container or Shipped by R&R |
| Name: | TECKING Aircraft Towing Tractor |
| Dimensions: | 7270*2600*1650mm |
| Towing Capacity: | 250T |
| Gross Vehicle Weight: | 25000 KG |
| Maximum Speed: | 30km/h |
| Min. Turning Diameter: | 11800 mm |
| Front Hitch Ground Clearance: | 330 mm |
| Front Hook Ground Clearance: | 300 mm |
| Company Info. |
| chongqing dima industry co.,ltd |
| View Contact Details |
| Product List |
Aircraft Tow Tractor For Airplane Pushback For A321 With 180KN
Aircraft Tow Tractor The HF6150 series aircraft, using the newest European technology, is designed to push and pull all know narrow body and ro certain extend medium body aircrafts.
The max draw bar pull for this series is up to 180KN The aircraft includes B717; B727; B737; B757; B767-200; A318; A319; A320; A321; A300; A310 or any aircraft below 300,000 kg. It ergonomic designed provides agility, visibility, durable and reliable tractors. One of the unit designs is that it has three antenna type safety swithces, similar to other raised cab heavy tractor.
Any one of these touches an onstacle, it will stop the vehicle completely. This will prevent any accident happened.
Description:
The TK-QY200 aircraft tow tractor offers reliable aircraft push and pull service in full compliance with CAAC andinternational standards, such as, IATA AHM 905, IATA AHM 910, IATA AHM 913, IATA AHM915, IATAAHM 916, IATA AHM 955,MH/T6017 etc.
Specifications for Aircraft Tow Tractor:
| Dimensions | Performance | ||
| Overall Dimensions | 7270*2600*1650mm | Tow Bar Pull | 180 KN |
| Wheel Base | 2750 mm | Towing Capacity | 250000 KG |
| Front/Rear AxleTread | 2230mm | Gross Vehicle Weight | 25000 KG |
| Ground Clearance | 200 mm | Maximum Speed | 31 km/hr |
| Min. Turning Diameter | 11800 mm | ||
| Front Hitch Ground Clearance | 265/395 mm | ||
| Rear Hitch Ground Clearance | 370/470 mm |
Applicable Aircraft:
A300-600,A310-200, A310-300, A321, A318,A319, A320,A330-200, A330-300, B717, B737, B757,B767-300, B767-400, B787-3, B787-8, B787-9
|
