| Categories | D Sub Connector |
|---|---|
| Brand Name: | Ritian communication |
| Model Number: | DP-44Pin |
| Certification: | UL CE ROHS |
| Place of Origin: | Guangdong, China |
| MOQ: | 100 PCS |
| Price: | Negotiable |
| Supply Ability: | 100000 Unit/Units per Month |
| Delivery Time: | 5-7 days |
| Packaging Details: | Box Packing,1000Pcs/CTN |
| Max Withstand Volt: | AC 500 volts |
| Pin: | A: 5PIN / B: 25PIN / C: 37PIN / D: 50PIN / E: 9PIN |
| Electrical character: | PBT UL94V-0 |
| housing: | ABS UL94V-0 |
| Model: | D sub |
| application: | Power, industrial process automation and control drives |
| rated current: | 3A |
| Gender: | male Female |
| insulation resistance: | MIN: 1000MΩ (DC500V) |
| Company Info. |
| Dongguan sun Communication Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
HDP 44P FEMALE ST DIP 44 Pin D-SUB Connector
| D-sub Connector Major Technical Characteristics | |
| Voltage Rating | 300V AC/ rms 50Hz |
| Withstanding Voltage | 1000V AC/ rms 50Hz for one minute |
| Insulation Resistance | 1000MΩ at 500V DC |
| Contact Resistance | 20 MΩ max. |
| Single Contact Insertion Force | 1.19 lb. (0.54 kg.) max. |
| Single Contact Withdrawal Force | 0.13 lb. (0.06 kg.) min. |
| Operating Temperature | -67°F (-55°C) to +257°F (125°C) |
| Number of Pins | A=15 Pin , B=25 Pin , C=37 Pin , D=50 Pin , E=9 Pin |
Technical Specifications:
| Item | D sub waterproof connector |
| Feature: | accompliance with IEC60807-2 waterproof series, With locking and with screen contact type |
| flexiable installation way, Various locking elements and cable clamps and outlet boxes | |
| Series inclusion: | Divide into A,B,C ,E mode according to the shell number, contacting elements include mixture and signal types. |
| Base material: | PBT exterior shell: PBT or PA |
| exterior shell and surface treatment: | Front nickel plated, thick tin plated |
| Contact: | Copper alloy, solderable wire, soldering plate, all gold plated or can be customized |
| Termination method | Flexible press-in, substrate welding, wire bonding, etc. |
| waterproof grade: | IP67, IP65 and can be customized |
| Main Technical parameters: | |
| Working Voltage: | 300V |
| Rated Current: | 30A/ 40A |
| Pressure resistance: | 1000V |
| Insulation resistance | ≥2000MΩ |
| working temperature: | -45C°-125C° |
| Contact resistance: | ≤0.004Ω |
| Flame retardant grade: | UL94V-0 |
| Life: | 500 times |
Application range
1. Audio/video products: MP3, MP4, DVD, sound system
2. Digital equipment: digital camera, digital video recorder
3. Remote control: vehicles, rolling doors, home security products
4. Communication products: mobile phones, car phones, telephones,
building equipment, PDA, etc.
5. Household appliances: TV sets, microwave ovens, rice cookers,
hair dryers, electronic scales, body fat water scales, kitchen
scales.
6. Security products: videophone, monitor, etc.
7. Toys: electronic toys, etc.
8. Computer products: cameras, recording pens, etc.
9. Fitness equipment: treadmills, massage chairs, timers, etc.
10. Medical equipment: blood pressure monitors, thermometers,
hospital call systems and similar products.
|
