Manual Horizontal Tilt Dual Axis Fine Adjustment Chamber Positioning Stage

Manual Horizontal Tilt Dual Axis Fine Adjustment Chamber Positioning Stage

The manual horizontal tilt stage is widely used for positioning with cameras, sensors, etc. It can be combined with displacement tables, direct motion tables, optical lens calibration and adjustment sensors for positioning; Used for two-dimensional position adjustment of optical components, fine adjustment of XY axis spatial positioning, and other purposes.

Product characteristics

1. The horizontal tilt stage can be combined with displacement table, direct motion table, optical lens calibration and adjustment sensor for positioning;

2. Maximum adjustable ± 4 º tilt resistance load (4 kgf);

3.There is a 6mm through-hole on the bottom surface for fixation;

4. The 16mm screw hole on the workbench can be used in conjunction with various optical components;

5. M4 threaded holes are opened at the four corners of the countertop to allow for the installation of optical components;

Product specification parameters

The manual linear stage of PDV has multiple travel options, ranging from 6mm to 50mm, and even longer large area platforms. Most displacement and translational platforms can be assembled into a multi axis system, providing XY or XYZ multi axis translation. In addition to standard linear displacement tables, we also provide rotary displacement tables, pitch deflection displacement tables, and angle displacement tables.

Beijing PDV Instrument Co., Ltd is a collection of optics, precision machinery, automatic control technology independent high-tech research and development enterprises. Since 2005, we have been serving the scientific research institutes and universities. We have developed the hardware and software system (optical path construction, software development, mechanical circuit design, etc.) according to the needs of customers. Through long-term unremitting efforts, the process of building the system to control the optical path and excellent service to customers, we’ve grown into a well-known manufacturer among scientific research, colleges and universities, machinery automation and many other areas.

The company designs and produces telephoto lens, automatic mechanical console, manual console, ultra brightness light source and other products. The products focus on modularization and integration, and have formed mass production. They have complete specifications and good quality. At the same time, they provide customized services. With excellent quality, the products are widely used in electronic and precision industrial testing, laboratory and measuring instrument industries, scientific research institutions, and exported to overseas markets such as Japan, South Korea, Europe and the United States.

The company has strong technical force and has a group of professional teams engaged in R & D, production and sales of optoelectronic products for a long time. It has extensive professional experience in displacement precision adjustment, motion control, precision image measurement and so on.

We hope to become your reliable partner with perfect products and reasonable price, and win your support.
