2W 3W 4W SMD LED Chips 620-630nm 520-530nm 450-470nm 6000-7000K 70-90lm

Name: 2W 3W 4W SMD LED Chips 620630nm 520530nm 450470nm 60007000K 7090lm
Brand: Learnew Opto
Price: 1 USD

2W 3W 4W SMD LED Chips 620-630nm 520-530nm 450-470nm 6000-7000K 70-90lm

Categories	SMD LED Chips
Brand Name:	Learnew Opto
Model Number:	LN-SMD5054RGBW-P4-LYH
Certification:	CE/ROHS
Place of Origin:	China
MOQ:	5000
Price:	Negotiable
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	600000
Delivery Time:	7-15 work days
Packaging Details:	Choose packaging materials with better cushioning and protection effect. For lamps with higher value or lamps with more glass surface, we use the outer box and add a wooden box or wooden frame to the packaging.
Name:	5054RGBW LED
POWER:	2-4W
CCT:	W=6000-7000K
LUMINUOUS EFF:	W=70-90lm
SIZE:	5.0*5.4MM
LES:	R5.0MM
VIEW ANGLE:	120°
SUBSTRATE:	PCT

Contact Now

Add to Cart

Company Info.

Shenzhen Learnew Optoelectronics Technology Co., Ltd.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

2W 3W 4W SMD LED Chips 620-630nm 520-530nm 450-470nm 6000-7000K 70-90lm

Learnew Oem Odm Factory SMD LED chips 2W 3W 4W 620-630nm 520-530nm 450-470nm6000-7000K 70-90lm for Disinfection LED Lamp

5054 led chip Product specification

PART NUMBER

POWER

CCT

LUMINUOUS EFF

CHIPS

IF

VF

CIRCUIT

WHOLE SIZE

LES

VIEW ANGLE

SUBSTRATE

LN-SMD5054RGBW-P2-LYH

2W

R=620-630nm
G=520-530nm
B=450-470nm
W=6000-7000K

R=30-40lm
G=60-70lm
B=20-30lm
W=70-90lm

SANAN CHIP

150mA

R=2.0-2.4V
G=3.0-3.4V
B=3.0-3.4V
W=3.0-3.4V

1PCS in series
1PCS in parallel
4 circuit

5.0*5.4MM

R5.0MM

120°

PCT

LN-SMD5054RGBW-P4-LYH

4W

R=620-630nm
G=520-530nm
B=450-470nm
W=6000-7000K

R=30-40lm
G=60-70lm
B=20-30lm
W=70-90lm

SANAN CHIP

300mA

R=2.0-2.4V
G=3.0-3.4V
B=3.0-3.4V
W=3.0-3.4V

1PCS in series
1PCS in parallel
4 circuit

5.0*5.4MM

R5.0MM

120°

PCT

LN-SMD5054RGB-P3-LYH

3W

R=620-630nm
G=520-530nm
B=450-470nm

R=30-40lm
G=60-70lm
B=20-30lm

SANAN CHIP

300mA

R=2.0-2.4V
G=3.0-3.4V
B=3.0-3.4V

1PCS in series
1PCS in parallel
3 circuit

5.0*5.4MM

R5.0MM

120°

PCT

5054 RGBW LED Chip Design Advantage

PCT leadframe.
High ESD pass.
Standard A Class chips.
Cost performance.
Gold wire bond.
Easy reflow sodering.

5054 RGBW LED Chip Application

LED stage light
LED landscape lighting
